TYRSY-08A/08B Multifunctional Edge Grinder

1.Universal wheels and roller brushes types could meet your different business needs 2.Easy attached to the washing machine 3.Extensible platforms give you more flexibility on your glass size 4.Workable to the special-shaped edging, like the straight-edged, rounded, triangular, wavy and other shapes 5.Adjustable grinding wheel and removable alignment
  • TYRSY-08A/B

Availability:

Product Description


RSY-08A


RSY-08B


Description

This series machine is especially suitable for processing glass rounded corners and car windshields. Widely used for different glass specifications without manual adjustment repeatedly. This machine could be connected with the washing machine from its front or side position, therefore to make the processing line more smoothly and result in a manpower and time saving. What is more, it has zero influence to the existing connected four-side grinding and other mechanical equipment. This series machine solves the problems such as rough edges during glass processing, easy cracking in high temperature furnace, and secondary chipping.



◆ Features


  • Universal wheels and roller brushes types could meet your different business needs

  • Easy attached to the washing machine

  • Extensible platforms give you more flexibilities on your glass size

  • Workable to the special-shaped edging, like the straight-edged, rounded, triangular, wavy and other shapes

  • Adjustable grinding wheel and removeable alignment wheels


◆ Specification


Model

RSY-08A

RSY-08B

Power

2.3KW

2.3KW

Overall size

2840*1250*850mm

2800*1250*850mm

Adaptive glass   thickness

3mm-12mm

3mm-12mm

Minimum processing size

280*280mm

300*300mm

Maximum processing size

2000*2000mm

2000*2000mm


◆ Pictures Showing





X08B1  X08B2
