Automatic Laminated Glass Cutting Machine

1、optimize layout
2、automatic stripping
3、production database
4、high-speed quartz tube heating
5、belt conveyor
6、Chinese and English interface
  • XC-LM3826

  • TOYOCC

Availability:
Quantity:

Product Description

Automatic Laminated Glass Cutting Machine




             laminated                    glass cutting


                          laminated gutting                            cutting





※ Characteristic

1.Easy operation, high cutting precision

2.International standard steel with perfect surface treatment

3.Key area was annealed and milled, which ensures the high stability and intensity

4.Cutting and breaking pressure adjustable

5.Far-infrared heating temperature and heating time adjustable

6.Machine includes three sections and bridge frame

The first two sections are glass loading and transfer area with auto location system and mechanical location device The third section has functions of glass stretch and glass break

7.Bridge frame is the center of the cutting system, which includes up and down double cutters, upper clamp and film far-infrared cutting


※  Major function

1.optimize layout

2.automatic stripping

3.production database

4.high-speed quartz tube heating

5.belt conveyor

6.Chinese and English interface


※ Main mechanical parts:

☆ Rack and rail: KHK Japan

☆ Guide rail: Hiwin Taiwan

☆ Cutter wheel and cutter holder: Bolhe Germany


※ Main electric parts:

☆ CNC System: Galil (USA)

☆ Servo motor: NMH (Germany)

☆ Pneumatic parts: Airtec (Taiwan)

☆ Low voltage electric parts: Schneider (France)

☆ Cutting pressure valve: SMC (Japan)



※  Technical parameter:

Machine Name

Automatic Laminated Glass Cutting Machine

Model

XC-LM3826

Max. Glass Sheet Size

3700*2500mm

Min. Glass Cutting Size

400*250mm

Glass Thickness

3+3mm-------12+12mm

Heating Temperature and Time

Can be adjustable

Max. Cutting Speed

120m/min

Dimensions

7100*4500*1500mm

Weight

3000KG


Laminated Glass Cut Flow Chart


Set cutting glass length and width

Load glass on air float table

Air blower start

Move glass to auto location area

Air blower stop

Cutting head back origin

Cutting head moves to start cutting point

Cutting head drops to glass surface to cut glass by pneumatic control

Cutting head rises back after cut

Glass clamp start

Bottom crossbeam move to break glass

Heating start

Sucking disc start to stretch glass

Film knife start to cut film
